DRY BLOCK


Contact Us

Provides the most convenient, portable facilities for checking & calibrating industrial probes and they are usually reasonable rapid heating and cooling device. The unit consists of a specially designed heating block which has located internal holes for the probes. Although the block temperature is accurately controlled, any indication provided should be used for guidance only. As with any comparison technique, a certified sensor and indicator should be used to measure the block temperature and used as a reference for the test probe. Two types of unit are available; portable units which can be taken on to plant for the on-site calibration and laboratory units to which industrial sensors are brought as required.



Devices
Temperature Range(°C)
Stability(°C)
Calibration Volume(mm)
Calsys -15/110

-15 to 110
0.1
Dia 24 * 300(L) (2 holes of 6.5, 2  holes of 8.5)
Calsys 650
50 to 650
0.1
Dia 32 * 150(L), 4 holes of 6.5 * 120(D)
Calsys FB
50 to 650
0.1
Dia 150 * 385(D)
Calsys 1200
250 to 1200
1
Dia 37 * 215(L), (2*6&2*8 holes) * 160(D)
Calsys 1200L
300 to 1200
0.5
Dia 37 * 240(L), (2*6&2*8 holes) * 160(D)
Calsys 1200 3Z
300 to 1200
0.4
Dia 37 * 240(L), (2*6&2*8 holes) * 160(D)
Calsys 1500L
500 to 1500
1
Dia 37 * 245(L), (2*6&2*8 holes) * 140(D)
Calsys 1700L

500 to 1700
2
Dia 37 * 240(L), (2*6&2*8 holes) * 225(D)
